Miracle M300 (LINUX)

Linux Smart POS Terminal

  • LINUX
  • 2.8" TFT QVGA 320×480 touch
  • 4G + 2G + Wi-Fi 2.4 GHz + BT 4.2
  • Li-polymer 3.7 V 2600 mAh
  • 1 Micro + 1 Normal + 1 SAM
  • 146.9 × 79 x 57 mm 285 g
Download Catalog:

Description

The Miracle M300 Linux is a compact, powerful, and reliable smart payment terminal built on a stable Linux operating system. It combines enterprise-grade security with excellent usability, making it the perfect choice for retail, restaurants, delivery services, and mobile businesses.

Key Features:

  • Stable Linux Operating System – Fast, secure, and highly customizable
  • PCI PTS 7.x Certified – Highest payment industry security standard
  • EMV L1 & L2 Certified – Full compliance with global card schemes
  • Glass Surface Keyboard with Backlight – Durable and easy to use in any lighting condition
  • Powerful Performance – Smooth operation even under heavy load
  • Long-Lasting Battery – Up to 5200mAh for extended field use
  • Rich Connectivity – 4G, Wi-Fi, Bluetooth
  • NFC Payment Ready – Support for contactless transactions

Why Choose Miracle M300 Linux?

  • Proven Stability – Linux OS ensures reliable performance 24/7
  • Compact & Rugged – Ideal for mobile and counter use
  • Advanced Security – Full PCI and EMV certification with secure key management
  • User-Friendly – Backlit glass keyboard and clear display for comfortable operation

The Miracle M300 Linux is the smart choice for businesses seeking a cost-effective, secure, and dependable payment solution with the flexibility of Linux.

Technical Specifications

OS:

LINUX

Processor:

AP: ARM CORTEX-A7 1.2 GHZ

SP: 32 bit Cortex- MO 96MHz

Memory:

AP 128 MB RAM + 16 MB Flash

Card Readers:

Chip & PIN / NFC / Magnetic Stripe

NFC Reader:

13.56 MHz ISO/IEC 14443 A/B

Camera:

0.3 MP rear

Display:

2.8" TFT QVGA 320×480 touch

Comms:

4G + 2G + Wi-Fi 2.4 GHz + BT 4.2

Battery:

Li-polymer 3.7 V 2600 mAh

Printer:

30 lines/s, Ø 40 mm roll

SIM/SAM:

1 Micro + 1 Normal + 1 SAM

Keys:

Numeric x10 + Function x8 + Power x1

Audio:

Buzzer

USB:

Type-C OTG

Adapter:

Input AC 100-240 V Output 5 V/1 A

Size/Weight:

146.9 × 79 x 57 mm 285 g

Temperature:

-10~ 50 °C operation

Certifications:

PCI 7.x/ EMV L1/L2 / EMV Pure Kernel Support

Charger:

5V 1A

Cable:

1m TypeA-TypeC

GPS:

AGPS, GPS, GLONASS, BEIDOU(optional)
